Waterproof LED outdoor spotlights

First check the real exposure of the location, then choose the protection rating accordingly: under a canopy, IP44 is enough; facing rain and watering jets, go one step higher. This collection brings together waterproof outdoor LED spot lights to plant on a stake, recess into the ground or surface-mount with adjustable direction, to light a facade, a terrace or a garden.

Is an IP44 rating enough for outdoors?

An IP44 protects against water splashes and fine dust: it is enough under a canopy, a porch or a covered terrace, never in full wind facing the elements or near a pond. As soon as the spot receives rain, watering jets or pressure washing, you move to a higher rating.

What is the difference between IP44, IP65 and IP67?

The two digits are read separately: the first rates protection against dust and solid objects, the second against water. An IP65 withstands jets, an IP67 temporary immersion, an IP68 prolonged immersion. For an exposed facade or terrace edge, the second digit decides.

What does an airtight waterproof outdoor LED spot mean?

An airtight housing does not let moisture circulate between the inside of the spot and the outside: the seal and the cable gland form a barrier. This is what limits fogging behind the glass and protects the module. A well-tightened spot keeps this promise, a spot opened for adjustment then closed by hand no longer does.

To locate the relevant models, browse the outdoor LED spot collection, which groups the different outdoor installations.

Where to install waterproof outdoor LED spot lights?

A waterproof outdoor LED spot is installed where traffic and sight lines stop: path, entrance, facade corner, terrace, around a bed. In a sheltered area, a moderate rating is enough; facing rain or near a pond, choose a higher rating and an installation away from standing water.

Black waterproof outdoor LED spots: which finish on a dark facade?

On a dark wall, a black finish makes the housing disappear and leaves only the light visible, which suits a stone wall or a dark render. On a light facade, a black housing instead draws visible marks when switched off. In that case, look at the black finishes for a dark wall and the white outdoor LED spots for a light wall.

Can a waterproof outdoor LED spot be installed in a bathroom?

Yes, in a zone protected from direct splashes, away from the bathtub and shower. An outdoor spot finds its place there thanks to its seal and material: aluminium, stainless steel or polycarbonate depending on the model, with tempered glass or a diffuser that resists moisture. The logic remains the same as outdoors: real exposure dictates the rating.

Under a canopy or covered terrace: recessed ceiling spots or LED wall light?

Under a canopy, a recessed or adjustable spot fixed to the ceiling lights the table and the ground without taking up wall space. An LED wall light, on the other hand, spreads more widely against the wall and lights the passage. The two combine: the spot defines the worktop or table, the wall light illuminates the area where people move. For all the families, see the full range of Designix lighting.

What are the differences between a stake spot, a recessed ground spot and an adjustable spot?

A stake spot moves and installs without work, on a bed or a border. A recessed ground spot integrates into a terrace, a path or a slab and requires a recess and drainage. An adjustable spot is surface-mounted, on a wall or ceiling, and is aimed at the point to highlight.

Waterproof adjustable outdoor LED spot: what it allows on a facade

Adjustment changes everything on a wall: aiming downwards and slightly at an angle, the beam grazes the material and brings out the relief without sending light towards the street. Compare the adjustable spots and the recessed adjustable spots depending on whether you mount on the surface or into a support.

Waterproof recessed ground LED spot: what to plan before pouring the slab

A recessed spot is decided before the concrete: a recess of the right size, a conduit run under the slab, a low point for water drainage. A black model blends into a dark paving, as shown by the black recessed spots. After the slab, recessing becomes a repair job.

What light for a facade, a terrace or a garden?

For atmosphere, a warm white relaxes a terrace and a dining corner, a neutral white stays readable for a path or an entrance, a cool white is reserved for traffic areas. The important thing is to choose a single family of light for the whole garden, otherwise the facades turn into a patchwork.

Warm, neutral or cool: which colour temperature outdoors?

Around 2700 to 3000 K, you are in a warm white, the one for terraces and dining corners. Around 4000 K, neutral white renders colours naturally and suits paths and entrances. Above 5000 K, cool white marks contrasts and is reserved for car parks and vigilance zones, never for a residential facade.

How to light a facade without blinding the neighbours?

Aim the beams downwards or towards the wall, never towards the horizon. A narrow angle concentrates the light on a detail, a wide angle spreads it over the wall. Space the points rather than aligning them continuously, and aim at the material, stone or render, rather than the window opposite.

For a graphic result, modern style spots pair well with a clean wall, while metal spots play on the visible material.

How to connect an outdoor LED spot: 230 V, 12 V, transformer or dimmer?

A 230 V outdoor spot connects directly to the mains, with a waterproof box or terminals. A 12 V model goes through a suitable transformer, to be installed in a sheltered place. Dimming is only possible if the spot and its power supply are designed for it, otherwise choose a model with a dedicated dimmer.

Can an outdoor LED spot be connected to a dimmer?

Only if the spot and power supply combination accepts dimming. A model with an integrated dimmer, or controllable by a compatible dimmer, is then adjusted to use: lower for a terrace dinner, higher for moving around. The dimmable spots and the recessed dimmable spots cover both installations.

Do you need a transformer for 12 V outdoor LED spots?

Yes, a 12 V never connects directly to the mains. The transformer is placed indoors, in a technical duct or under a protected box: it is the sensitive part of the installation. 12 V suits low power and damp areas, 230 V suits long runs and numerous spots.

How to waterproof an outdoor spot?

Waterproofing comes from the seal and the tightening, not from silicone added afterwards. Tighten the cable glands, point the cable downwards so water drains, keep the seal clean and avoid opening the spot once installed. A poorly tightened cable entry is enough to let moisture in.

How to install a garden LED spot with stake and waterproof socket?

Mark the position, push in the stake without forcing on the cable, run the wire away from mowing areas, then close the cover of the outdoor socket. Check that the socket stays high up, never laid on the ground in a hollow. The solar outdoor spots without wiring avoid the problem when no power point is available.

How to protect a spot recessed into a terrace?

Plan a drain or a gravel bed under the housing, direct the conduit towards a low point and make sure the slab does not form a water trap above the glass. Clear the dead leaves that block the drainage, because standing water wears a seal faster than rain. Before winter, a tightening and a look at the seal are enough.

What mistakes to avoid with outdoor LED spots?

The mistakes that cost dearly are almost always the same: recessing before running the cables, choosing the finish after the facade is done, aiming the spots towards the street or a neighbour's window, or relying on a single very powerful point instead of several discreet points.

Plan the recess and cables before pouring a slab

Once the concrete is poured, adding a recessed spot means breaking, running a new conduit and redoing the waterproofing by hand. The fix is simple: fix the spot positions on a plan, run the conduits, install the housings, then pour. The same logic applies to a staircase, where marking comes before masonry, as for step and staircase lighting.

Relying on a single very powerful spot instead of several points

A single point creates an overexposed patch and leaves the rest of the wall in the dark. Several discreet sources, distributed and slightly aimed at the material, give relief and consume less for a softer result. The fix is to reduce the unit power and multiply the positions.

How to distribute outdoor LED spots between path, terrace and beds?

Light in touches: a few points on the facade, one or two on the path, one on the bed, rather than a continuous alignment. Better to space the spots and vary the heights to create relief, avoiding crossing two beams on the same area.

Should you light the whole facade or only a few points?

A few well-placed points, at a wall corner or either side of an opening, are enough to give a facade its scale. A wall drowned in light loses its relief and tires the eye. For a facade with character, outdoor spots with a crafted design bring a visible line when switched off.

How to light steps or a path without blinding?

Aim at the step and not the person: the beam goes down onto the riser or the ground, never at eye level. One point at the start, one at direction changes, one in front of a step or an obstacle make the path readable without multiplying the sources. An outdoor staircase follows exactly the same rule as indoors.

Secure payment, tracked delivery, returns and Designix customer service: you order with no risk. Browse all outdoor LED spots to compare installations, finishes and protection ratings, or return to see all our lighting to light the whole house.

Frequently asked questions about waterproof outdoor LED spots
