Recess the fixture so that it sits flush with the surface: that is what gives a grazing light on a threshold or a wall, with no protrusion to catch the eye. The cut-out diameter is given on the product sheet; the spotlight requires 13.5 cm of free depth, and is recognisable by its silver metal finish and its GU10 base.
What is a recessed outdoor spotlights IP67?
A recessed outdoor spotlights IP67 is a fixture that is recessed into the support and sits flush with the surface. The IP67 rating makes it dust-tight and resistant to splashes, with resistance to temporary immersion. The model in the collection is made of silver metal, round, with a GU10 base and 20 W maximum.
The effect is that of a point of light set flush with the support, with no visible housing. On a terrace, this highlights a step or a low wall without putting the source in the field of view. To compare formats, the family of recessed outdoor spotlights brings together the different mounting variants.
Recessed outdoor spotlights IP67: what the protection rating says
Two digits, two protections. The first concerns dust, the second liquids. An IP67 rating announces dust tightness and resistance to splashes as well as temporary immersion. It is the level that allows recessing into a terrace floor or into a damp room, where a fixture only protected against splashes would wear out faster.
What a flush spotlight changes on a terrace
The light starts from the ground, grazes the slab and draws out the relief instead of lighting flat. The Elvor round silver spotlight plays this role with a 12 cm metal disc, in a minimalist style that does not overshadow the furniture.
| Criterion | Value |
|---|---|
| Material | Metal |
| Colour | Silver |
| Base | GU10 |
| Maximum power | 20 W |
| Protection rating | IP67 |
| Dimensions | Ø 12 cm, height 13.5 cm |
Where to install a recessed IP67 spotlight in the home and outdoors?
The same IP67 spotlight is suitable for outdoors, the terrace, the kitchen, the hallway, the living room and the bathroom. It is recessed into a ceiling, a soffit or a hard floor. The 13.5 cm height must be available above the support, and the power is limited to 20 W.
For a recessed floor spotlight, check the impact resistance rating (IK) and the load capacity, as well as the presence of stainless steel and an adjustable colour temperature.
| Location | What we look for | To check |
|---|---|---|
| Outdoors | Mark a threshold or a path | IP67, GU10 base, 20 W max |
| Kitchen | Light the worktop | Beam directed downwards |
| Hallway | Guide without dazzling | Power limited to 20 W |
| Bathroom | Resist splashes | IP67 rating |
| Living room | Punctuate a wall or a piece of furniture | Silver colour, minimalist style |
Can an IP67 spotlight be installed in a kitchen or hallway ceiling?
Yes, on two conditions. There must be room: a 12 cm cut-out and 13.5 cm of free depth. You also need to aim at a useful area rather than the centre of the room, for example to light a kitchen worktop. In a hallway, the same principle is used to guide light in a hallway without dazzling.
Terrace, threshold, bathroom: where waterproofing really matters
Outside, rain and jet washing justify IP67. In the bathroom, it is splashes and condensation. In a living room, a spotlight intended for the living room is often enough, but IP67 remains comfortable near a bay window or a floor washed with plenty of water.
How to arrange spotlights in a ceiling?
Spotlights are arranged on an axis or in a regular line, kept away from the wall to avoid a cast shadow, and placed above the areas of use rather than in the empty centre of the room. Each round spotlight requires a 12 cm cut-out and 13.5 cm of free depth.
How to distribute spotlights in a room without leaving shadow areas?
Start from the uses: a table, a worktop, a passage. Each area gets its point, then you complete for atmosphere. Too close together, spotlights create patches; too far apart, they leave dark pockets. A recessed spotlight with a discreet effect forgives gaps better than a model with strong relief.
Should spotlights be aligned with the wall or with the furniture?
Align with the line the eye follows: the edge of a piece of furniture, a wall, a row of doors. A misaligned line is more noticeable than imperfect spacing. If the beam needs to change direction, an adjustable recessed spotlight corrects the aim without re-drilling.
How many spotlights in a kitchen?
The number of spotlights in a kitchen is counted by area to be lit: worktop, sink, hob, dining area. One point is placed above each useful area, then you complete for atmosphere. A GU10 spotlight of 20 W maximum is enough for directed lighting.
How many spotlights above a worktop and a sink?
As many as there are actual workstations. One point above the sink, one above the preparation area, one near the hob if the worktop is long. Better one point per use than a regular row lighting the gap between two units.
Open kitchen: how to avoid spotlights dazzling
Aim downwards and keep the power low. Avoid placing a spotlight in the line of sight from the living room. The LED version for the kitchen allows you to lower the power while keeping sharpness on the worktop.
How to install recessed spotlights in a ceiling?
Mark the points, drill at the diameter of the fixture, here 12 cm, after checking that 13.5 cm of depth are free. The power is switched off, the wires connected, the GU10 bulb fitted, then the spotlight clips into the hole and sits flush with the ceiling.
- Mark and draw the axes, check for the absence of joists and conduits.
- Drill at the diameter of the fixture, 12 cm.
- Check the 13.5 cm of free depth.
- Switch off the power, connect the wires, fit the GU10 bulb.
- Clip the spotlight in and check that it sits flush.
What depth is needed above a recessed spotlight?
13.5 cm for this model, which corresponds to its height. In a plasterboard ceiling on a frame, the measurement is taken between the visible face and the first obstacle. A false ceiling that is too low means you must read the technical sheet before drilling, including on the LED range for outdoors.
How to fit a spotlight without damaging the ceiling finish
Drill with a hole saw suited to the board, without forcing, and protect the surface around the hole. The spotlight clips in, it is not screwed into the board: no excessive tightening, so no cracks around the disc.
How to wire spotlights in series or in parallel?
On a 230 V installation, GU10 spotlights are wired in parallel: each receives the same voltage and works independently. Series wiring is reserved for very low voltages, because it divides the voltage between the fixtures and makes the light drop.
Why avoid wiring 230 V spotlights in series?
In series, the voltage is shared between the fixtures. Two spotlights on 230 V no longer receive the intended voltage, the light drops and the installation becomes unpredictable. In parallel, each GU10 socket sees the same voltage and switching off one point does not cut the others.
Parallel wiring and dimmer on the same line
Adjustment is made from the line control. This spotlight is dimmer compatible, which aligns all the points on the same line to the same light level. To harmonise a whole room, compare with the dimmer-compatible models before choosing the control.
E27 outdoor bulb or GU10 base: what to choose for a recessed spotlight?
The E27 base takes large bulbs and does not fit into a compact recessed fixture. The spotlight in this collection uses a GU10 base, which is shorter and allows a round fixture 12 cm in diameter sitting flush with the support. The choice of base therefore determines the final format of the spotlight.
Why a compact recessed spotlight uses a GU10 base
The GU10 socket is short and the bulb stays contained within the body of the fixture. That is what allows a total height of 13.5 cm and a 12 cm disc. An E27 bulb, longer and wider, would require a much deeper housing.
Changing the bulb of a recessed outdoor spotlight
Switch off the line, let it cool, unclip the spotlight or unscrew the ring depending on the mounting, then replace the GU10 bulb respecting the 20 W maximum. The GU10 base is an easy standard to find, which matters when upgrading lighting towards all LED outdoor solutions.
How to match a recessed spotlight with an outdoor terrace wall light?
On a terrace, the recessed spotlight stays discreet and grazing, while the outdoor wall light brings a high point on the wall. They are matched by keeping colours close, a consistent metal and a comparable intensity, with a shared dimmer to balance both sources together.
Is a shared dimmer needed for the spotlight and the wall light?
It is not compulsory, but it is what avoids the contrast between a brightly lit wall and an almost unlit floor. A single setting controls the whole when both fixtures share the same line. For a terrace without wiring, solar spotlights without wiring avoid running a power supply.
Silver metal and light colours: how to combine finishes
Silver goes well with light facades, weathered wood and concrete. On a very dark wall, a black outdoor spotlight blends in better than a light metal disc. The rule remains simple: a single family of shades for the spotlight and the wall light, and two sources that answer each other without competing. If you want to go lighter, the outdoor range in light colours stays in the same spirit.
The Elvor spotlight can be ordered in a few clicks, with secure payment, tracked delivery and returns, and the Designix customer service answers installation questions. To compare it with other formats, browse all our light fixtures. If the beam needs to be directed towards a wall or a step, look instead at the adjustable versions to direct.
Frequently asked questions about recessed outdoor spotlights IP67
Can a recessed IP67 spotlight be installed in a bathroom?
Yes. The IP67 rating makes the spotlight dust-tight and resistant to splashes as well as temporary immersion, which covers damp rooms. However, you need 13.5 cm of free height above the support and a 12 cm diameter cut-out.
Does a recessed outdoor spotlight work with a dimmer?
The Elvor spotlight is dimmer compatible. Adjustment is made from the line control, provided the dimmer is intended for the installation. All the spotlights connected on this same line then follow the same light level, which simplifies matching with a wall light.
Which bulb for a recessed IP67 spotlight?
The spotlight in the collection takes a GU10 base bulb, with a maximum power of 20 W. The GU10 socket is short, which allows the round fixture 12 cm in diameter to stay flush with the support, without protruding from the surface.
How to arrange spotlights in a ceiling?
Spotlights are placed on a regular line or axis, kept away from the wall to avoid a cast shadow, and above the areas actually used rather than in the empty centre of the room. Check the space available above the ceiling, 13.5 cm here, before drilling.
How to light a terrace with an outdoor wall light and recessed spotlights?
The wall light places the light high on the wall, the recessed spotlight keeps it flush with the floor or ceiling. Keep colours and material consistent between the two, and a shared dimmer allows the whole to be balanced without creating too marked a contrast between the wall and the slab.
