Recessed brass spotlights

A brass recessed spotlight is chosen on three points: the finish (white, gold or black in this collection of 4 products), the GU10 base limited to 7.5 W per bulb, and the IP44 rating that allows installation near a water point. The round adjustable model measures 8 cm high for 7.9 cm in diameter, accepts a dimmer and is installed in the living room, kitchen, hallway, on a terrace or outdoors.

• What light does a brass recessed spotlight give?
• Where to install it in the house?
• Adjustable, colour and base
• Arranging the spotlights on the ceiling
• Installing and wiring
• How many spotlights in a kitchen?
• Chandelier or recessed spotlights
• Caring for the gold finish

What is a brass recessed spotlight and what light does it give?

A brass recessed spotlight is here a round spotlight that is built into a flat ceiling and whose direction is adjusted after installation. It takes a GU10 bulb of 7.5 W maximum, accepts a dimmer and has an IP44 protection rating. The light starts from a precise point and is then directed towards a wall, a worktop or a passageway.

Brass recessed spotlight: which finish to choose?

The mount combines aluminium and plastic, and the spotlight is offered in white, gold and black. The word brass describes here the golden look of the finish, not the material of the mount: it is an aesthetic indication. The gold tone matches brass taps, light wood or a mineral worktop; white disappears into a painted ceiling, black marks a light ceiling or dark joinery. Compare the range of brass spotlights, the gold finish of recessed spotlights and the metal spotlights.

What light for a living room or a hallway?

The spotlight does not set the colour of the light: the GU10 bulb does. In general, aim for 2700 to 3000 K for a living room where you sit in the evening, and a slightly crisper 3000 K in a hallway without windows, to read the doors and steps. A dimmer lets you lower the intensity at the end of the day. The direction of the beam does the rest: towards the wall in the living room, towards the floor in a passageway. See the adjustable recessed spotlights.

Where to install a brass recessed spotlight in the house?

The rooms documented for this spotlight are the living room, kitchen, hallway, terrace and outdoors, as well as the bathroom in compliance with the IP44 rating. Marking out is done before cutting: ceiling height, routing of conduits, work areas and water points. Each room then keeps its own installation logic.

Brass recessed spotlight bathroom: what IP44 allows

IP44 protects the spotlight from water splashes, which is suitable around a washbasin or a mirror. In general, installation rules distinguish several zones around the bath and the shower, and this single rating is not enough to install a spotlight in the most exposed zone. For a bright and discreet room, see the white recessed spotlights.

Recessed spotlight for terrace and outdoors

Under a covered terrace, IP44 protects against splashes and ambient humidity. Direct exposure to rain is not covered by this single rating: check the actual shelter before fixing the location, and keep the spotlight adjustable to aim at a wall or a planting. Find the recessed outdoor spotlights and adjustable outdoor spotlights.

How to choose your brass recessed spotlight: adjustable, colour and base?

Choose in this order: the base and the power first, since they determine the bulb; the protection rating next, according to the room; the finish last, once the installation is decided. The model in the collection is GU10, limited to 7.5 W per bulb, adjustable, with IP44 and dimmer compatibility.

Brushed or aged brass recessed spotlight: what to look at?

A brushed brass gives a matte and uniform look, an aged brass seeks a more contrasted appearance. Here, the colours actually offered are white, gold and black: the look is therefore judged on the gold tone, not on ageing. Look at the light in the room, a gold tone warms up under warm lighting, then at the match with the handles, taps and wall lights already installed. To harmonise several sources, start from the Designix lighting catalogue.

Which base and which power for a recessed spotlight?

The GU10 base is a bayonet base: the bulb is fitted with a quarter turn and can be changed without tools. The limit of 7.5 W per bulb frames the choice, and common GU10 LED bulbs reach a good level of illumination well below this ceiling. It is the direction and the number of points that set the mood, not the power. Full details are on the Kalkanessa adjustable IP44 spotlight.

How to arrange spotlights on the ceiling?

Start from the areas to be lit, not from a number of spotlights: worktop, passageway, wall to highlight. Then align the points on lines parallel to the walls, with a regular spacing, because irregular spacing is immediately noticeable on a ceiling. The direction of the spotlight finally corrects small angle differences.

What spacing between two spotlights on the ceiling?

There is no universal figure: the spacing depends on the ceiling height and the beam opening of the bulb. In general, the higher the ceiling, the more the points are spaced out, and the more directional the bulb, the closer they are to avoid dark areas. Measure the room, divide the length by the number of points considered, then check the result on the floor with a temporary marker before drilling. See the design recessed spotlights.

How to place spotlights in a hallway?

In a hallway, align the spotlights on the central axis or on two lines along the walls, keeping a clear distance from the ends so as not to light empty space. Avoid the plumb line of an open door and the axis of a view towards a mirror. The Ø 7.9 cm and the height of 8 cm require checking the space in the ceiling thickness, especially when renovating. More guidance on the spotlights for hallways.

How to install recessed spotlights in the ceiling?

Switch off the power at the consumer unit, mark the points, check that there are no obstacles and the available thickness, then cut. The spotlight measures 8 cm high and 7.9 cm in diameter: the space above the ceiling must accommodate it without pinching the cables. Finish with the connection, fitting the GU10 bulb and a test before closing up the work.

Preparing the cut-out and cable routing

First locate the conduits and the position of the joists, then draw the chosen diameter in pencil and check the alignment from one point to the next before the first cut. Route the cables without tension, leave enough slack to bring the spotlight out of its housing when changing a bulb, and keep the instructions to hand for the connection.

How to wire spotlights: series or parallel?

In parallel, each spotlight receives power from the circuit: this is the usual arrangement, and a blown bulb does not switch off the others. In series, the spotlights follow one another on the same wire, which changes their power supply. On this GU10 model, follow the instructions and have the diagram validated by an electrician. See the dimmer-compatible models.

How many spotlights in a kitchen?

The number depends on the surface area, the height and the work areas: count the points needed above the worktops, then those for circulation and storage. As the power is limited to 7.5 W per bulb, work on the number and the direction rather than on the power. Two regular lines are better than a saturated ceiling.

Spotlights above the worktop

Place the point so that your body does not cast a shadow on the worktop when you cook: slightly in front of the worktop, not just behind your back. A beam directed towards the wall avoids glare when you look up. Other configurations on the recessed spotlights for kitchens and the recessed LED spotlights for kitchens.

General lighting or worktop lighting?

A ceiling of spotlights alone flattens the room: keep a few points for general lighting and concentrate the others on the worktop, the hob and the sink. A dimmer makes the transition from serving to eating more comfortable. Compare the adjustable recessed LED spotlights.

Brass chandelier or recessed spotlights: which solution to choose?

A brass chandelier provides a central and decorative light point; recessed spotlights free up the ceiling and light several areas. The spotlight in the collection is round, adjustable, GU10, IP44 and dimmer-compatible. The choice comes down to ceiling height and use: central decoration on one side, distributed lighting on the other.

Brass chandelier: when to prefer it?

A chandelier takes its place when the room has height, a identifiable centre, and you want a visible object above a table or a living room. It becomes the focal point of the decor and concentrates the light. It does, however, require a central power supply and is not suitable for a low ceiling. To match it with the rest, see all the lighting in the house.

Recessed spotlights: when to prefer them?

Spotlights have the advantage in a hallway, a kitchen, a low ceiling or a through room where the light must be distributed without occupying the volume. The result remains understated and leaves the field free for decoration. For a living room, see recessed lighting for the living room.

How to care for a brushed brass recessed spotlight?

Dust dry with a soft cloth, switch off the power before any intervention, and check once a year that the bulb is tight and the direction moves freely. The aluminium and plastic mount does not require a specific product, only gentleness.

Cleaning the gold finish without scratching it

Avoid scouring pads, abrasive powders and acidic products, which mark the tone and leave micro-scratches visible in raking light. A slightly damp then wrung-out cloth is enough on the trim, and a dry cloth finishes. To vary the finishes on the same ceiling, see the black recessed version.

What to check after installation?

After a few days, check that the spotlight holds in its housing, that the GU10 bulb is properly locked with a quarter turn and that the rotation remains free, without a stiff point. A direction that forces indicates excessive tightening. If you add a dimmer, check the compatibility of the bulb to avoid flickering.

Order the spotlight from the collection

The Kalkanessa adjustable IP44 spotlight is available in white, gold and black, with a 2-year warranty. Choose the finish according to the ceiling and the handles, then the GU10 bulb according to the desired light colour: the fixture is the same, the result changes. Secure payment, tracked delivery, returns and Designix customer service accompany the order.
